Equipment of NMR department

© Dr. K. Bergander

The NMR laboratory of Organic Chemistry is furnished with a wide range of equipment, creating the opportunity for a large variety of different NMR experiments to be carried out. Below, a list of NMR spectrometers with their specific accessories and capabilities is detailed. Further, specialized NMR experiments can be performed on request.

  • DD2 600 (Agilent)

    Contact:

    Equipment:

    • Four channels
    • Probes:  One-NMR, HFX, HCX, HPX
    • Temperature control from -100 to +100 °C
    • Sample changer for 12 samples

    Topics:

    • Structure elucidation with modern 1D and 2D pulse sequences
    • NMR measurements at low concentration
    • 19F-NMR: X{1H,19F}, 1H{19F,X} and 19F{1H,X} triple resonance experiments, HOESY
    • Pulse sequences with selective irradiation, e.g. 1D-TOCSY, 1D-dpfgNOE
    • Band- and multiselective decoupling
    • Homo- and heteronuclear NOE and ROE measurements
    • DOSY
    • X nuclei
    • Dynamic NMR and kinetics at variable temperature
    • Special experiments
  • DD2 500 (Agilent)

    Contact:

    Equipment:

    • Three channels
    • Probes:  AutoX-DB, BB, ID
    • Temperature control from -100 to +100 °C
    • Samplechanger for 12 samples

    Topics:

    • Structure elucidation with modern 1D and 2D pulse sequences
    • NMR measurements at low concentration
    • Dynamic NMR and kinetics at variable temperature
    • Pulse sequences with selective irradiation, e.g. 1D-TOCSY, 1D-dpfgNOE
    • X nuclei measurements
  • NEO 400a (Bruker)

    Contact:

    Equipment:

    • Three channels
    • iProbes:  C/H/F-TBO and BBFO-Smart
    • Samplechanger for 60 samples (SampleCase)

    Topics:

    • 1D and 2D NMR service measurements in automation mode
    • 1H, 19F and X nuclei
    • 13C{1H,19F}-spectra
    • 13C and DEPT at low sample concentration
  • NEO 400b (Bruker)

    Contact:

    Equipment:

    • Two channels
    • iProbes:  13C-19F/1H-SmartProbe
    • Samplechanger for 60 samples (SampleCase)

    Topics:

    • 1D Service measurements in automation mode
    • 1H, 13C, DEPT
    • 19F, 7Li, 11B, 29Si, ...
  • NEO 400c (Bruker) - OpenAccess OC

    Hint:

    • We've just started to introduce the coworkers for the open access run!

    Contact and responsible for the introduction of group members:

    Equipment:

    • Two channels
    • Probe:  13C-19F/1H-SmartProbe
    • Samplechanger for 60 samples (SampleCase)

    Topics:

    • 8 am - 20 pm: 1H-, 19F{1H}-, 31P{1H}- and 11B{1H}-spectra
    • 20 pm - 8 am and on the weekend:  in addition 13C{1H}, DEPT

    Operation mode:

    • Open access for trained group members of OC
    • Set up of night measurements: not before 7 am!
    • Remove samples from completed measurements that belong to your group
    • Delete completed measurements from the autosampler queue after removing the samples

    Technical support:

    • Completed by the coworkers of the NMR department. In return, the spectrometer is available for service measurements, if other spectrometer are out of order.



  • Avance II 300 - group of Prof. Dr. A. Studer

    Contact and responsible for the introduction of group members:

    Equipment:

    • Two channels
    • Probe:  BBFO
    • BACS Samplechanger for 60 samples

    Topics:

    • 1D NMR for product control
    • 1H, 13C, DEPT, 19F, 11B, 31P

    Operation mode:

    • Open access for group members

    Technical support:

    • Completed by the coworkers of the NMR department. In return, the spectrometer is available for service measurements, if other spectrometer are out of order.
